Product Overview

• The JST 3 Pin Header Data Cable is designed for connecting electronic devices with JST 3-pin connectors. It is widely used in electronic projects, development boards, and other DIY electronics. This cable provides reliable connections, ensuring stable signal transmission suitable for various electronic applications.

1. Product Specifications

• Connector Type: JST 3 Pin (available in SH or PH types)
• Pitch: 1mm (SH) or 2.54mm (PH)
• Cable Length: 30cm, 50cm, 100cm (custom lengths available upon request)
• Wire Gauge: 26AWG (suitable for general current transmission)
• Color Coding: Common wire colors (e.g., red, black, yellow) for easy identification and connection
• Temperature Range: -20°C to +80°C, adaptable to various environmental conditions
• Durability: Made from high-flexibility materials, abrasion-resistant, ensuring long-term stability in use

2. Product Types and Uses

• Pre-Wired Cable: Ideal for quick connections, reducing manual soldering time, allowing users to rapidly assemble circuits in projects.
• Signal Transmission Cable: Used for signal transmission and power connections, widely applied in robotics, sensors, and development board projects, ensuring stable data transfer.
• Debugging and Testing Cable: Facilitates debugging and testing during electronic development, helping developers quickly identify issues.

3. Compatibility

• Compatible with various electronic devices and development boards, such as Arduino, Raspberry Pi, ESP8266, ESP32, etc., ensuring seamless connection with existing devices for diverse project needs.

4. Purchase Channels

• Available for purchase on major electronic component supplier websites, DIY electronics stores, and online e-commerce platforms (Trycay), making it easy for users to select and acquire.

5. Usage Guide

• Provides detailed wiring instructions and usage information to help users get started quickly. The guide includes:
  • How to identify the polarity of the connector
  • Illustrated wiring steps and explanations (with visual examples)
  • Frequently asked questions to assist with common user queries

6. Precautions

• Ensure the correct pitch and cable length are chosen to meet specific project requirements, avoiding connection issues due to mismatched specifications.
• Pay attention to polarity during connections to prevent short circuits or device damage, ensuring safe usage.

7. Related Product Recommendations

• JST 2 Pin Connector Data Cable
• JST to USB Adapter Cable
• Other specifications of JST connectors and accessories, such as 4 Pin, 5 Pin connectors, to meet different project needs.

Summary

The JST 3 Pin Header Pin Data Cable is a versatile and flexible data connection solution, suitable for the various project needs of electronics enthusiasts, engineers, and students. With detailed product specifications and usage guides, users can more easily select and utilize this product, enhancing project efficiency and reliability.
